Product Name : | New Arrival Alytimes Aly011 Cheap Supper Mini Cube 720P IP cam with onvif, 128GB TF card slot, built-in microphone and speaker |
| Product Origin : | China | |
| Product Category : | Network/IP cameras | |
| More Products : | Click here! | |
| Contact Details : | Shenzhen Alytimes Technology Co., LTD | |
| Product Code : | aly011 |
Product Details
| System | Main Processor | Hisilicon processor,built-in ARM9 and a high-speed video co-processor. |
| Operating system | Embedded Linux OS | |
| Lmage Sensor | Sensor | High Definitioin Color CMOS Sensor |
| Display Resolution | 1280*720 (1.0 Megapixel) | |
| Min.Illuminatioin | 0.1 Lux / F1.2 (With IR Illuminator) | |
| Lens | Lens Type | Glass Lens |
| Lens Parameter | Focal Length：3.6 mm; Aperture：F 2.4 | |
| Angle of View | 90° | |
| Video | Image Compression | H.264. |
| Image Frame Rate | 30fps maxmium, downward adjustable | |
| Resolution | 720P(1280 x 720), VGA(640 x 360), QVGA(320 x 180) | |
| Image Adjustment | Automatic | |
| Flip Mirror Image | Automatic (Built-in gravity sensing system, Auto filp mirror image) | |
| Infrared Mode | Automatic | |
| Night Visibility | 6pcs IR-LEDs, night vision range up to 8 metres | |
| Audio | Coding Standards | G.711A. |
| Input / Output | Supports two-way audio, Built-in Mic & Speaker | |
| Record | microSD Card | Support 128G microSD Card.( only support FAT32 file system format) |
| Record Mode | Alarm Record; Motion Detection Alarm Record; Timing video; Manual Record. | |
| Record Standard | VGA @ 25 fps | |
| Playback | Support remote playback. | |
| Network | Wireless | Standard IEEE 802.11 b/g/n, Security support :WEP, WPA, WPA2 Encryption. |
| Online Visitor | Online Visitor LAN support 10 people, WAN support 5 people. | |
| Onvif | Support Onvif Protocol, Support NVR (above Onvif version 2.4.2) | |
| Alarm | Alarm | Supports Motion detection, Phone push, Email and Whistle alarm. |
| Others | Product Type | Plastic/ Indoor Use |
| DC Power | DC5V/1A.. | |
| Working Temperature | 0~55 °C | |
| Working Humidity | 10%- 90% RH | |
| Size | Item size: 68mmx168x 110mm (LxWxH) | |
| Packaging size:160mmx140mmx55mm(LxWxH) | ||
| Weight | N.W.:150g G.W.: 350g (Note:Actual Weight Final) | |
| Accessories | Adaptor, User Manual, USB Wire, Bracket,Screw. | |
| System Required | SmartPhone & TablePC | Support iOS and Android system, Provide free App "APCam" |
| PC | Only support remote monitor on Internet Explorer(IE) browser. | |
| Certification | CE,FCC,RoHS | |
| Warranty | Limited 2-Year Warranty | |
